Eccentric Lockout Kit for Subaru GR86/BRZ/GT86/WRX
Brand : SPL Parts
- Part Number:
- SPL EL FRS
The stock eccentric bolts provided for small toe adjustments tend to slip under high cornering loads, causing changes to the rear alignment. The SPL eccentric lockout kit eliminates the stock eccentric bolts to keep your rear alignment where you set it.
Benefits
- Eliminates OEM Eccentrics, Locks Down Rear Alignment
- One Less Failure Point on Track Day
Materials
- 6061-T6 Aluminum Lock Plates
- Metric Class 10.9 Steel Bolts
Noise, Vibration, and Harshness (NVH)
The eccentric lockouts have no impact to NVH.
Featured On
Larry Chen's Turbo GR86 Track Car
Devin's VA STI Track Car
Sold as a pair. One pair per vehicle.
Confirmed Applications
2021+ Toyota GR86 (ZN8)
2013 - 2021 Toyota 86 / Scion FR-S (ZN6)
2013+ Subaru BRZ (ZC6/ZD8)
2008 - 2021 Subaru WRX / STI (GR/VA)
2008 - 2019 Subaru Outback
2010 - 2019 Subaru Legacy
2009 - 2018 Subaru Forester
ADJUSTABLE TOE ARMS REQUIRED
You will need adjustable toe arms to be able to align the car.
We offer a kit that includes toe arms and the eccentric lockouts:
We also offer just the toe arms:
Rear Adjustable Toe Arms for the Toyota GR86 / GT86 / FR-S / Subaru BRZ / WRX
Installation Instructions
Simply remove the OEM eccentric bolt and replace with the lockout kit in the same location. The lockout plates go on the outside of the subframe tabs and are clamped by the supplied bolt. Verify the plates are unable to move and are retained by the OEM indendation.
